SDR1006-100KL
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
SDR1006 Nonstandard 0.386Lx0.386W 9.80mmx9.80mm 10muH
PDF
/
Buying Options
Total Price: USD $0.69
Unit Price: USD $0.686877
≥1 USD $0.686877
≥10 USD $0.647996
≥100 USD $0.611323
≥500 USD $0.576721
≥1000 USD $0.544074
Inventory: 8415
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Material - Core Ferrite
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Published 2006
Series SDR1006
Size / Dimension 0.386Lx0.386W 9.80mmx9.80mm
Tolerance ±10%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Type Wirewound
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Composition Wirewound
Current Rating (Amps) 2.6A
Shielding Unshielded
Depth 9.8mm
Current Rating 2.6A
Base Part Number SDR1006
Military Standard Not
Inductance 10μH
Test Frequency 1kHz
DC Resistance (DCR) 60mOhm Max
Max DC Current 2.6A
Frequency - Self Resonant 21MHz
Q @ Freq 30 @ 2.52MHz
Inductance Frequency - Test 1kHz
Current - Saturation 5.1A
Q Factor 30
Inductance Tolerance 10%
DC Current 2.6A
Dimensions
Height 5.8mm
Height Seated (Max) 0.228 5.80mm
Length 9.8044mm
Width 9.8044mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
