SDR1005-152J
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
SDR1005 Nonstandard 0.500Lx0.394W 12.70mmx10.00mm 1.5mH
PDF
/
Inventory: 4913
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Material - Core Ferrite
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Published 2006
Series SDR1005
Size / Dimension 0.500Lx0.394W 12.70mmx10.00mm
Tolerance ±5%
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Type Wirewound
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Composition Wirewound
Current Rating (Amps) 250mA
Shielding Unshielded
Current Rating 250mA
Base Part Number SDR1005
Inductance 1.5mH
Test Frequency 1kHz
DC Resistance (DCR) 6.3Ohm Max
Max DC Current 250mA
Frequency - Self Resonant 2MHz
Q @ Freq 97 @ 131kHz
Inductance Frequency - Test 1kHz
Current - Saturation 300mA
Q Factor 91
Dimensions
Height 5mm
Height Seated (Max) 0.197 5.00mm
Length 12.7mm
Width 10.0076mm
Compliance
RoHS Status ROHS3 Compliant
Alternative Model
