PM628S-150-RC
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
PM628S Nonstandard 0.268Lx0.268W 6.80mmx6.80mm 15muH
PDF
/
Inventory: 4895
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mounting Type Surface Mount
Package / Case Nonstandard
Surface Mount YES
Terminal Shape ONE SURFACE
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Published 2009
Series PM628S
Size / Dimension 0.268Lx0.268W 6.80mmx6.80mm
Tolerance ±30%
JESD-609 Code e2
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Wirewound
Terminal Finish Silver/Nickel/Tin (Ag/Ni/Sn)
HTS Code 8504.50.80.00
Packing Method TR
Shielding YES
Number of Functions 1
Inductance 15μH
Test Frequency 0.1MHz
DC Resistance (DCR) 78mOhm Max
Max DC Current 1.7A
Frequency - Self Resonant 23MHz
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Q @ Freq 9.5 @ 2.52MHz
Inductance Frequency - Test 100kHz
Current - Saturation 1.3A
Case/Size Code 2727
Dimensions
Height 2.8mm
Height Seated (Max) 0.118 3.00mm
Compliance
RoHS Status ROHS3 Compliant
