SRU3028-150Y
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
SRU3028 Nonstandard 0.138Lx0.130W 3.50mmx3.30mm 15muH
PDF
/
Buying Options
Total Price: USD $0.74
Unit Price: USD $0.7392
≥1 USD $0.7392
≥10 USD $0.63624
≥100 USD $0.583264
≥500 USD $0.530112
≥1000 USD $0.471856
≥3000 USD $0.44535
Inventory: 1122
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.118 3.00mm
Height 2.8mm
Technical
Special Feature Q MEASURED AT 2.52MHZ
DC Current 660mA
Case/Size Code 1413
Q Factor 18
Current - Saturation 720mA
Quality Factor-Min (at L-nom) 18
Q @ Freq 18 @ 2.52MHz
Terminal Placement DUAL ENDED
Inductor Application POWER INDUCTOR
Frequency - Self Resonant 25MHz
Max DC Current 660mA
Current 240mA
DC Resistance (DCR) 230mOhm
Test Frequency 100kHz
Inductance 15μH
Military Standard Not
Current Rating 660mA
Construction Rectangular
Depth 3.5mm
Number of Functions 1
Shielding YES
Packing Method TR, Embossed, 7 Inch
HTS Code 8504.50.80.00
Terminal Finish Tin (Sn) - with Nickel (Ni) barrier
Type Wirewound
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance ±30%
Size / Dimension 0.138Lx0.130W 3.50mmx3.30mm
Series SRU3028
Published 2005
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Terminal Shape ONE SURFACE
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 18 Weeks
