PM1608-4R7M-RC
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
PM1608 Nonstandard 0.260Lx0.175W 6.60mmx4.45mm 4.7muH
PDF
/
Inventory: 6938
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mounting Type Surface Mount
Package / Case Nonstandard
Surface Mount YES
Terminal Shape WRAPAROUND
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Published 2009
Series PM1608
Size / Dimension 0.260Lx0.175W 6.60mmx4.45mm
Tolerance ±20%
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Wirewound
HTS Code 8504.50.80.00
Packing Method TR, Embossed, 7 Inch
Shielding NO
Number of Functions 1
Depth 4.45mm
Construction Rectangular
Military Standard Not
Inductance 4.7μH
Test Frequency 100kHz
DC Resistance (DCR) 90mOhm Max
Max DC Current 1.5A
Frequency - Self Resonant 50MHz
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Q @ Freq 17 @ 7.96MHz
Inductance Frequency - Test 7.96MHz
Case/Size Code 2618
DC Current 1.5A
Dimensions
Height 2.92mm
Height Seated (Max) 0.115 2.92mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
