9250-823
RoHS
/
Package Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description
9250 Axial 0.162Diax0.410L 4.11mmx10.41mm 82muH
PDF
/
Inventory: 9719
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Axial
Material - Core Ferrite
Shape/Size Description TUBULAR PACKAGE
Technical
Operating Temperature -55°C~105°C
Packaging Bulk
Published 2005
Series 9250
Size / Dimension 0.162Diax0.410L 4.11mmx10.41mm
Tolerance ±10%
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Wirewound
Shielding YES
Number of Functions 1
Construction Flame Retardant Coat
Current Rating 180mA
Lead Length 25.4mm
Inductance 82μH
Test Frequency 2.5MHz
DC Resistance (DCR) 2.44Ohm Max
Max DC Current 180mA
Frequency - Self Resonant 10.5MHz
Inductor Application RF INDUCTOR
Q @ Freq 50 @ 2.5MHz
Quality Factor-Min (at L-nom) 50
Current - Saturation 140mA
Q Factor 50
Dimensions
Diameter 4.1148mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
