9250-561
RoHS
/
Package Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description
9250 Axial 0.162Diax0.410L 4.11mmx10.41mm 560nH
PDF
/
Buying Options
Total Price: USD $1.62
Unit Price: USD $1.61618
≥1 USD $1.61618
≥200 USD $0.644634
≥500 USD $0.623628
≥1000 USD $0.613124
Inventory: 3411
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Technical
Q Factor 43
Quality Factor-Min (at L-nom) 43
Q @ Freq 43 @ 25MHz
Inductor Application RF INDUCTOR
Frequency - Self Resonant 210MHz
Max DC Current 490mA
DC Resistance (DCR) 330mOhm Max
Test Frequency 25MHz
Inductance 560nH
Lead Diameter 0.635 mm
Lead Length 25.4mm
Current Rating 490mA
Construction Flame Retardant Coat
Number of Functions 1
Shielding YES
HTS Code 8504.50.80.00
Type Wirewound
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Tolerance ±10%
Size / Dimension 0.162Diax0.410L 4.11mmx10.41mm
Series 9250
Published 2005
Packaging Bulk
Operating Temperature -55°C~105°C
Physical
Shape/Size Description TUBULAR PACKAGE
Material - Core Ferrite
Package / Case Axial
Mounting Type Through Hole
Mount Through Hole
