9230-10
RoHS
/
Package Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description
9230 Axial 0.095Diax0.250L 2.41mmx6.35mm 390nH
PDF
/
Inventory: 6475
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Diameter 2.41mm
Technical
Q Factor 30
Quality Factor-Min (at L-nom) 30
Q @ Freq 30 @ 25MHz
Inductor Application RF INDUCTOR
Frequency - Self Resonant 380MHz
Max DC Current 640mA
DC Resistance (DCR) 300mOhm Max
Test Frequency 25MHz
Inductance 390nH
Lead Length 25.4mm
Current Rating 640mA
Construction Flame Retardant Coat
Number of Functions 1
Shielding NO
HTS Code 8504.50.80.00
Type Molded
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Tolerance ±10%
Size / Dimension 0.095Diax0.250L 2.41mmx6.35mm
Series 9230
Published 2006
Packaging Bulk
Operating Temperature -55°C~105°C
Physical
Shape/Size Description TUBULAR PACKAGE
Material - Core Phenolic
Terminal Shape WIRE
Package / Case Axial
Mounting Type Through Hole
Mount Through Hole
