70F185AI-RC
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description
70F Axial 0.160Diax0.250L 4.06mmx6.35mm 18muH
PDF
/
Inventory: 993
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Axial
Number of Pins 2
Material - Core Iron
Shape/Size Description TUBULAR PACKAGE
Technical
Operating Temperature -55°C~105°C
Packaging Bulk
Published 2007
Series 70F
Size / Dimension 0.160Diax0.250L 4.06mmx6.35mm
Tolerance ±5%
JESD-609 Code e1
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Wirewound
Resistance 2.28Ohm
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
HTS Code 8504.50.80.00
Shielding NO
Number of Functions 1
Construction Varnish Coating
Current Rating 229mA
Military Standard Not
Lead Length 31.75mm
Lead Diameter 635 μm
Inductance 18μH
Test Frequency 2.5MHz
DC Resistance (DCR) 2.28Ohm Max
Max DC Current 229mA
Frequency - Self Resonant 15MHz
Inductor Application HIGH VOLTAGE CHOKE
Q @ Freq 52 @ 2.5MHz
Quality Factor-Min (at L-nom) 52
Q Factor 52
DC Current 229mA
Dimensions
Diameter 4.06mm
Compliance
RoHS Status ROHS3 Compliant
