5800-101-RC
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description
5800 Axial 0.275Diax0.700L 6.99mmx17.78mm 100muH
PDF
/
Buying Options
Total Price: USD $1.26
Unit Price: USD $1.2584
≥1 USD $1.2584
≥10 USD $1.06304
≥100 USD $0.966592
≥500 USD $0.9086
≥1000 USD $0.75394
≥3000 USD $0.69593
Inventory: 1186
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Diameter 6.985mm
Technical
DC Current 632mA
Inductance Tolerance 10%
Current - Saturation 1.1A
Inductor Application HIGH CURRENT INDUCTOR
Max DC Current 632mA
DC Resistance (DCR) 210mOhm Max
Test Frequency 1kHz
Inductance 100μH
Lead Diameter 635 μm
Military Standard Not
Current Rating 632mA
Construction Bobbin Core
Number of Functions 1
Shielding NO
Current Rating (Amps) 800mA
HTS Code 8504.50.80.00
Resistance 208mOhm
Type Wirewound
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Tolerance ±10%
Size / Dimension 0.275Diax0.700L 6.99mmx17.78mm
Series 5800
Published 2007
Packaging Tray
Operating Temperature -55°C~105°C
Physical
Shape/Size Description TUBULAR PACKAGE
Material - Core Ferrite
Number of Pins 2
Package / Case Axial
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 16 Weeks
