WW1008R-241K
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR RoHS Compliant WRAPAROUND DUAL ENDED Fixed Inductor 125C 650MHz 880mOhm 240nH
PDF
/
Inventory: 8321
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Package / Case Nonstandard
Terminal Shape WRAPAROUND
Material - Core Ceramic
Shape/Size Description RECTANGULAR PACKAGE
Technical
Packaging Tape & Reel
Tolerance 10%
JESD-609 Code e3
Pbfree Code yes
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Tin (Sn)
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Composition Wirewound
HTS Code 8504.50.80.00
Packing Method TR, 7 Inch
Shielding Unshielded
Number of Functions 1
Depth 2.79mm
Current Rating 500mA
Inductance 240 nH
Test Frequency 25MHz
Max DC Current 500mA
Frequency - Self Resonant 650MHz
Inductor Application RF INDUCTOR
Terminal Placement DUAL ENDED
Quality Factor-Min (at L-nom) 45
Inductor Type GENERAL PURPOSE INDUCTOR
Case/Size Code 1008
DC Resistance (DCR) - Parallel 880mOhm
Inductance-Nom (L) 0.24 μH
Special Feature Q MEASURED AT 100 MHZ
Dimensions
Height 2.03mm
Height Seated (Max) 2.032mm
Length 2.921mm
Width 2.794mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
