SPD62-683M
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR RoHS Compliant Contains Lead WRAPAROUND fixed air core inductor 125C 1kHz 1.2Ohm 68muH
PDF
/
Inventory: 4903
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Package / Case Nonstandard
Terminal Shape WRAPAROUND
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Packaging Cut Tape (CT)
Tolerance 20%
JESD-609 Code e0
Pbfree Code no
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn63Pb37)
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Composition Wirewound
HTS Code 8504.50.80.00
Packing Method TR, 13 Inch
Shielding Shielded
Number of Functions 1
Depth 6.5mm
Current Rating 560mA
Inductance 68 μH
Test Frequency 1kHz
Max DC Current 560mA
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Inductor Type GENERAL PURPOSE INDUCTOR
Current - Saturation 560mA
Case/Size Code 2624
DC Resistance (DCR) - Parallel 1.2Ohm
Inductance-Nom (L) 68 μH
Dimensions
Height 3mm
Height Seated (Max) 2.9972mm
Length 6.604mm
Width 6.2mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Contains Lead
