SPD62-223M

API Delevan
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description RoHS Compliant Contains Lead 8504.50.80.00 Tape & Reel (TR) fixed air core inductor 125C 1kHz 400mOhm 22muH
PDF
/
Inventory: 1850
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Width 6.1976mm
Length 6.604mm
Height Seated (Max) 2.9972mm
Height 3mm

Technical

DC Resistance (DCR) - Parallel 400mOhm
Current - Saturation 1A
Max DC Current 1A
Test Frequency 1kHz
Inductance 22 μH
Current Rating 1A
Depth 6.5mm
Shielding Shielded
HTS Code 8504.50.80.00
Composition Wirewound
Min Operating Temperature -55°C
Max Operating Temperature 125°C
ECCN Code EAR99
Termination SMD/SMT
Pbfree Code no
Tolerance 20%
Packaging Tape & Reel (TR)

Physical

Material - Core Ferrite
Package / Case Nonstandard
Mount Surface Mount
