M39010-03-A561KS
RoHS
/
Package Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR Non-RoHS Compliant WIRE 8504.50.80.00 fixed air core inductor 105C 4.7MHz 10.5Ohm 560muH
PDF
/
Inventory: 3194
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Length 10.414mm
Technical
Inductance-Nom (L) 560 μH
Rated Current-Max 0.09A
DC Resistance (DCR) - Parallel 10.5Ohm
Inductor Type GENERAL PURPOSE INDUCTOR
Quality Factor-Min (at L-nom) 60
Inductor Application RF INDUCTOR
Frequency - Self Resonant 4.7MHz
Test Frequency 790kHz
Inductance 560 μH
Reference Standard MIL-PRF-39010/03
Current Rating 90mA
Number of Functions 1
Shielding Unshielded
HTS Code 8504.50.80.00
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Terminal Finish Tin/Lead (Sn63Pb37)
Resistance 10.5Ohm
ECCN Code EAR99
Number of Terminations 2
JESD-609 Code e0
Tolerance 10%
Packaging Tape & Reel (TR)
Physical
Shape/Size Description TUBULAR PACKAGE
Material - Core Ferrite
Terminal Shape WIRE
Package / Case Axial
Mount Through Hole
