B82141A1564J000
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description
RF Choke Bobbin Core 560uH 5% 100KHz 60Q-Factor Ferrite 75mA 16.5Ohm DCR AXL T/R
PDF
/
Inventory: 3497
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mounting Type Through Hole
Package / Case Axial
Material - Core Ferrite
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Series SBC
Size / Dimension 0.118Diax0.268L 3.00mmx6.80mm
Tolerance ±5%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Wirewound
Current Rating (Amps) 75mA
Shielding Unshielded
Inductance 560μH
DC Resistance (DCR) 16.5Ohm Max
Frequency - Self Resonant 2.2MHz
Q @ Freq 60 @ 796kHz
Inductance Frequency - Test 796kHz
Compliance
RoHS Status ROHS3 Compliant
