SPD73R-472M
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
ROHS3Compliant Wirewound Active Lead Free fixed air core inductor -55C~125C 100kHz 50mOhm Max 4.7muH
PDF
/
Buying Options
Total Price: USD $4
Unit Price: USD $3.9952
≥1 USD $3.9952
≥10 USD $3.344
≥100 USD $3.0536
≥500 USD $2.617296
≥1000 USD $2.399232
≥3000 USD $2.326509
Inventory: 1031
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape ONE SURFACE
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Published 2012
Series SPD73R
Size / Dimension 0.287Lx0.287W 7.30mmx7.30mm
Tolerance ±20%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Wirewound
HTS Code 8504.50.80.00
Packing Method TR, 13 Inch
Shielding YES
Number of Functions 1
Depth 7.8mm
Construction Rectangular
Current Rating 3.5A
Inductance 4.7μH
Test Frequency 100kHz
DC Resistance (DCR) 50mOhm Max
Max DC Current 3.5A
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Case/Size Code 2929
Dimensions
Height 3.9mm
Height Seated (Max) 0.154 3.90mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
