SPD73R-333M

API Delevan Inc.
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description SPD73R Nonstandard 0.287Lx0.287W 7.30mmx7.30mm 33muH
PDF
/
Inventory: 9901
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Height Seated (Max) 0.154 3.90mm
Height 3.9mm

Technical

Case/Size Code 2929
Terminal Placement DUAL ENDED
Inductor Application POWER INDUCTOR
Max DC Current 1.35A
DC Resistance (DCR) 240mOhm Max
Test Frequency 1kHz
Inductance 33μH
Current Rating 1.35A
Construction Rectangular
Depth 7.8mm
Number of Functions 1
Shielding YES
Packing Method TR, 13 Inch
HTS Code 8504.50.80.00
Terminal Finish Tin (Sn)
Type Wirewound
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance ±20%
Size / Dimension 0.287Lx0.287W 7.30mmx7.30mm
Series SPD73R
Published 2012
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C

Physical

Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Terminal Shape ONE SURFACE
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 18 Weeks
