SPD62R-472M
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
SPD62R Nonstandard 0.260Lx0.244W 6.60mmx6.20mm 4.7muH
PDF
/
Buying Options
Total Price: USD $1.95
Unit Price: USD $1.9536
≥1 USD $1.9536
≥10 USD $1.63504
≥100 USD $1.493184
≥500 USD $1.279872
≥1000 USD $1.2518
Inventory: 1718
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape WRAPAROUND
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Published 2010
Series SPD62R
Size / Dimension 0.260Lx0.244W 6.60mmx6.20mm
Tolerance ±20%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Wirewound
Terminal Finish Tin (Sn)
HTS Code 8504.50.80.00
Packing Method TR, 13 Inch
Shielding YES
Number of Functions 1
Depth 6.5mm
Construction RECTANGULAR PACKAGE
Current Rating 2A
Inductance 4.7μH
Test Frequency 100kHz
DC Resistance (DCR) 150mOhm Max
Max DC Current 2A
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Case/Size Code 2624
Dimensions
Height 3mm
Height Seated (Max) 0.118 3.00mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
