SPD127-274M
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
SPD127 Nonstandard 0.472Lx0.472W 12.00mmx12.00mm 270muH
PDF
/
Inventory: 2331
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape WRAPAROUND
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Published 2005
Series SPD127
Size / Dimension 0.472Lx0.472W 12.00mmx12.00mm
Tolerance ±20%
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Wirewound
Terminal Finish Tin/Lead (Sn/Pb)
HTS Code 8504.50.80.00
Packing Method TR, 13 Inch
Shielding YES
Number of Functions 1
Depth 12.8mm
Current Rating 1.1A
Inductance 270μH
Test Frequency 1kHz
DC Resistance (DCR) 520mOhm Max
Max DC Current 1.1A
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Case/Size Code 4747
Dimensions
Height 8mm
Height Seated (Max) 0.315 8.00mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
