SP1008-332K
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
Non-RoHS Compliant Wirewound Active J BEND Fixed Inductor -55C~125C 100kHz 527mOhm Max 3.3muH
PDF
/
Inventory: 7601
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 45 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape J BEND
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Published 2010
Series SP1008
Size / Dimension 0.115Lx0.105W 2.92mmx2.66mm
Tolerance ±10%
JESD-609 Code e0
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Wirewound
Terminal Finish Tin/Lead (Sn/Pb)
HTS Code 8504.50.80.00
Packing Method TR, 13 Inch
Shielding YES
Number of Functions 1
Depth 2.66mm
Construction Rectangular
Current Rating 477mA
Inductance 3.3μH
Test Frequency 100kHz
DC Resistance (DCR) 527mOhm Max
Max DC Current 465mA
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Saturation Current 823mA
Dimensions
Height 2.41mm
Height Seated (Max) 0.095 2.41mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
