S4924-821J

API Delevan Inc.
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description GENERAL PURPOSE INDUCTOR Non-RoHS Compliant Active WRAPAROUND Fixed Inductor -55C~125C 180MHz 590mOhm Max 820nH
PDF
/
Inventory: 4967
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 45 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape WRAPAROUND
Material - Core Phenolic
Shape/Size Description RECTANGULAR PACKAGE

Technical

Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Published 2010
Series S4924
Size / Dimension 0.520Lx0.250W 13.21mmx6.35mm
Tolerance ±5%
JESD-609 Code e0
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn63Pb37)
HTS Code 8504.50.80.00
Packing Method TR, 13 Inch
Shielding YES
Number of Functions 1
Depth 6.35mm
Construction Rectangular
Current Rating 800mA
Inductance 820nH
Test Frequency 25MHz
DC Resistance (DCR) 590mOhm Max
Max DC Current 800mA
Frequency - Self Resonant 180MHz
Inductor Application RF INDUCTOR
Terminal Placement DUAL ENDED
Q @ Freq 40 @ 25MHz
Quality Factor-Min (at L-nom) 40
Inductor Type GENERAL PURPOSE INDUCTOR
Q Factor 40
Case/Size Code 5225

Dimensions

Height 5.84mm
Height Seated (Max) 0.230 5.84mm

Compliance

Radiation Hardening No
RoHS Status Non-RoHS Compliant
