160-821KS

API Delevan
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description GENERAL PURPOSE INDUCTOR RoHS Compliant Contains Lead WRAPAROUND Fixed Inductor 125C 150MHz 260mOhm 820nH
PDF
/
Inventory: 1411
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Width 3.18mm
Length 3.81mm
Height Seated (Max) 2.032mm
Height 2.03mm

Technical

Inductance-Nom (L) 0.82 μH
DC Resistance (DCR) - Parallel 260mOhm
Case/Size Code 1613
Q Factor 50
Inductor Type GENERAL PURPOSE INDUCTOR
Quality Factor-Min (at L-nom) 50
Terminal Placement DUAL ENDED
Inductor Application RF INDUCTOR
Frequency - Self Resonant 150MHz
Max DC Current 695mA
Test Frequency 25MHz
Inductance 820 nH
Current Rating 695mA
Construction Chip
Depth 3.18mm
Number of Functions 1
Shielding Unshielded
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Terminal Finish Tin/Lead (Sn63Pb37)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Pbfree Code no
JESD-609 Code e0
Tolerance 10%
Packaging Bulk

Physical

Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Terminal Shape WRAPAROUND
Package / Case Nonstandard
Mount Surface Mount
