PTKM100R-121
RoHS
RoHS compliant
RoHS compliantPackage Radial, Vertical (Open)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
ROHS3Compliant Toroidal Active WIRE Fixed Inductor 2MHz 65mOhm Max 100muH ±10%
PDF
/
Inventory: 3109
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height 10.16mm
Technical
Current - Saturation 1.6A
Inductance Frequency - Test 1kHz
Inductor Application POWER INDUCTOR
Frequency - Self Resonant 2MHz
Max DC Current 3.24A
DC Resistance (DCR) 65mOhm Max
Test Frequency 1kHz
Inductance 100μH
Lead Diameter 0.71 mm
Lead Spacing 19.81mm
Lead Length 12.7mm
Lead Pitch 8.13mm
Current Rating 3.24A
Number of Functions 1
Shielding YES
HTS Code 8504.50.80.00
Terminal Finish Tin/Copper (Sn99.3Cu0.7)
Type Toroidal
ECCN Code EAR99
Termination Radial
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e2
Tolerance ±10%
Size / Dimension 0.820Diax0.400W 20.83mmx10.16mm
Series PTKMR
Published 2010
Packaging Bulk
Physical
Shape/Size Description CYLINDRICAL PACKAGE
Material - Core Ferrite
Terminal Shape WIRE
Package / Case Radial, Vertical (Open)
Mounting Type Through Hole
Mount Through Hole
