PTKM100-894VM
RoHS
/
Package Radial, Vertical (Open)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
Non-RoHS Compliant Toroidal Active WIRE Fixed Inductor 2MHz 23mOhm Max 100muH ±10%
PDF
/
Inventory: 4115
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 1.400 35.56mm
Height 35.56mm
Technical
Current - Saturation 3.5A
Inductance Frequency - Test 1kHz
Inductor Application POWER INDUCTOR
Frequency - Self Resonant 2MHz
Max DC Current 8A
DC Resistance (DCR) 23mOhm Max
Test Frequency 1kHz
Inductance 100μH
Lead Diameter 1.295 mm
Lead Length 6.35mm
Lead Pitch 15.24mm
Current Rating 8A
Number of Functions 1
Shielding YES
HTS Code 8504.50.80.00
Terminal Finish Tin/Lead (Sn/Pb)
Type Toroidal
ECCN Code EAR99
Termination Radial
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e0
Tolerance ±10%
Size / Dimension 1.450Lx0.825W 36.83mmx20.95mm
Series PTKM-VM
Published 2010
Packaging Bulk
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Terminal Shape WIRE
Package / Case Radial, Vertical (Open)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
