PTKM10-50SM
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
PTKM-SM Nonstandard 0.700Lx0.670W 17.78mmx17.02mm 10muH
PDF
/
Inventory: 3839
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 0.400 10.16mm
Height 10.16mm
Technical
Case/Size Code 7067
Current - Saturation 1.7A
Terminal Placement DUAL ENDED
Inductor Application POWER INDUCTOR
Frequency - Self Resonant 35MHz
Max DC Current 7.36A
DC Resistance (DCR) 10mOhm Max
Test Frequency 1kHz
Inductance 10μH
Current Rating 7.36A
Construction Rectangular
Depth 17.02mm
Number of Functions 1
Shielding YES
HTS Code 8504.50.80.00
Terminal Finish Tin/Lead (Sn/Pb)
Type Toroidal
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Part Status Active
Pbfree Code no
JESD-609 Code e0
Tolerance ±10%
Size / Dimension 0.700Lx0.670W 17.78mmx17.02mm
Series PTKM-SM
Published 2002
Packaging Bulk
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Terminal Shape ONE SURFACE
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
