PTHF250-50
RoHS
/
Package Radial, Vertical (Open)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
Non-RoHS Compliant Toroidal Active WIRE Fixed Inductor 1.5MHz 160mOhm Max 250muH ±10%
PDF
/
Inventory: 9925
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial, Vertical (Open)
Terminal Shape WIRE
Material - Core Molybdenum Permalloy(MPP)
Shape/Size Description CYLINDRICAL PACKAGE
Technical
Packaging Bulk
Published 2010
Series PTHF
Size / Dimension 0.625Diax0.300W 15.87mmx7.62mm
Tolerance ±10%
JESD-609 Code e0
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination Radial
ECCN Code EAR99
Type Toroidal
Terminal Finish Tin/Lead (Sn/Pb)
HTS Code 8504.50.80.00
Shielding YES
Number of Functions 1
Current Rating 1.84A
Lead Pitch 6.35mm
Lead Length 12.7mm
Inductance 250μH
Test Frequency 1kHz
DC Resistance (DCR) 160mOhm Max
Max DC Current 1.84A
Frequency - Self Resonant 1.5MHz
Inductor Application POWER INDUCTOR
Inductance Frequency - Test 1kHz
Current - Saturation 900mA
Dimensions
Diameter 15.87mm
Height 15.875mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
