PD104R-474K
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
ROHS3Compliant Wirewound Active ONE SURFACE fixed air core inductor -55C~125C 1kHz 1.53Ohm Max 470muH
PDF
/
Inventory: 8070
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 0.157 4.00mm
Height 4mm
Technical
Case/Size Code 3935
Terminal Placement DUAL ENDED
Inductor Application POWER INDUCTOR
Max DC Current 350mA
DC Resistance (DCR) 1.53Ohm Max
Test Frequency 1kHz
Inductance 470μH
Current Rating 350mA
Construction Rectangular
Depth 9.2mm
Number of Functions 1
Shielding NO
Packing Method TR, 13 Inch
HTS Code 8504.50.80.00
Terminal Finish Tin (Sn)
Type Wirewound
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance ±10%
Size / Dimension 0.386Lx0.346W 9.80mmx8.79mm
Series PD104R
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Terminal Shape ONE SURFACE
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
