P1330R-154K

API Delevan Inc.
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description P1330R Nonstandard 0.313Lx0.115W 7.94mmx2.92mm 150muH
PDF
/
Buying Options
Total Price: USD $2.71
Unit Price: USD $2.7104
≥1 USD $2.7104
≥10 USD $2.26688
≥100 USD $2.06976
≥500 USD $1.774256
≥1000 USD $1.626328
≥3000 USD $1.577101
Inventory: 66
Minimum: 1
-
+

Technical Details

Technical

Max DC Current 272mA
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Inductor Type GENERAL PURPOSE INDUCTOR
Current - Saturation 106mA
Case/Size Code 3313
DC Resistance (DCR) 2.04Ohm Max
Test Frequency 1kHz
Inductance 150μH
Lead Length 1.02mm
Current Rating 272mA
Construction Rectangular
Depth 3.18mm
Number of Functions 1
Shielding NO
Packing Method TR, 13 Inch
HTS Code 8504.50.80.00
Terminal Finish Tin/Silver/Copper (Sn96.5Ag3.0Cu0.5)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e1
Tolerance ±10%
Size / Dimension 0.313Lx0.115W 7.94mmx2.92mm
Series P1330R
Published 2005
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C

Dimensions

Height 3.683mm
Height Seated (Max) 0.145 3.68mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free

Physical

Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Terminal Shape WRAPAROUND
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 12 Weeks
