SD52-151-R
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
SD52 Nonstandard 0.205Lx0.205W 5.20mmx5.20mm 150muH
PDF
/
Inventory: 4613
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Number of Pins 2
Weight 453.59237mg
Material - Core Ferrite
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Published 2006
Series SD52
Size / Dimension 0.205Lx0.205W 5.20mmx5.20mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Type Wirewound
Resistance 1.61Ohm
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Composition Wirewound
Current Rating (Amps) 310mA
Shielding Shielded
Current Rating 310mA
Inductance 150μH
Test Frequency 100kHz
DC Resistance (DCR) 1.61Ohm
Max DC Current 280mA
Inductance Frequency - Test 100kHz
Current - Saturation 280mA
Dimensions
Height 2mm
Height Seated (Max) 0.079 2.00mm
Length 5.1816mm
Width 5.1816mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
