P1330-183J
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR Non-RoHS Compliant Active WRAPAROUND Fixed Inductor -55C~125C 1kHz 328mOhm Max 18muH
PDF
/
Inventory: 9722
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape WRAPAROUND
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Published 2010
Series P1330
Size / Dimension 0.325Lx0.125W 8.26mmx3.18mm
Tolerance ±5%
JESD-609 Code e0
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
HTS Code 8504.50.80.00
Packing Method TR, 7 Inch
Shielding NO
Number of Functions 1
Depth 3.18mm
Current Rating 817mA
Inductance 18μH
Test Frequency 1kHz
DC Resistance (DCR) 328mOhm Max
Max DC Current 817mA
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Inductor Type GENERAL PURPOSE INDUCTOR
Current - Saturation 420mA
Case/Size Code 3111
Dimensions
Height 3.68mm
Height Seated (Max) 0.145 3.68mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
