MILP1812-153K

API Delevan Inc.
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description GENERAL PURPOSE INDUCTOR Non-RoHS Compliant Active WRAPAROUND Fixed Inductor -55C~130C 1kHz 780mOhm Max 15muH
PDF
/
Inventory: 4150
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 15 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape WRAPAROUND
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE

Technical

Operating Temperature -55°C~130°C
Packaging Tape & Reel (TR)
Published 2013
Series MILP1812
Size / Dimension 0.189Lx0.134W 4.80mmx3.40mm
Tolerance ±10%
JESD-609 Code e0
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
HTS Code 8504.50.80.00
Packing Method TR, 7/13 Inch
Shielding NO
Number of Functions 1
Depth 3.4mm
Current Rating 450mA
Inductance 15μH
Test Frequency 1kHz
DC Resistance (DCR) 780mOhm Max
Max DC Current 450mA
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Inductor Type GENERAL PURPOSE INDUCTOR
Current - Saturation 693mA
Special Feature REFERENCE STANDARD: MIL-PRF-27/368

Dimensions

Height 3.4mm
Height Seated (Max) 0.134 3.40mm

Compliance

Radiation Hardening No
RoHS Status Non-RoHS Compliant
