HF1008R-122K

API Delevan Inc.
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description GENERAL PURPOSE INDUCTOR ROHS3Compliant Active WRAPAROUND fixed air core inductor -55C~125C 200MHz 1.45Ohm Max 1.2muH
PDF
/
Inventory: 8448
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 45 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape WRAPAROUND
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE

Technical

Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Published 2012
Series HF1008R
Size / Dimension 0.115Lx0.105W 2.92mmx2.66mm
Tolerance ±10%
JESD-609 Code e1
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn96.5Ag3.0Cu0.5)
HTS Code 8504.50.80.00
Packing Method TR, 13 Inch
Shielding NO
Number of Functions 1
Depth 2.66mm
Construction Rectangular
Current Rating 320mA
Inductance 1.2μH
Test Frequency 7.9MHz
DC Resistance (DCR) 1.45Ohm Max
Max DC Current 320mA
Frequency - Self Resonant 200MHz
Inductor Application RF INDUCTOR
Terminal Placement DUAL ENDED
Q @ Freq 30 @ 7.9MHz
Quality Factor-Min (at L-nom) 30
Inductor Type GENERAL PURPOSE INDUCTOR
Q Factor 30

Dimensions

Height 2.41mm
Height Seated (Max) 0.095 2.41mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
