ER1840-36JM
RoHS
/
Package Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description
Non-RoHS Compliant Molded Active WIRE fixed air core inductor -55C~105C 24MHz 2.2Ohm Max 22muH
PDF
/
Inventory: 7530
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Technical
Quality Factor-Min (at L-nom) 60
Q @ Freq 60 @ 2.5MHz
Inductor Application RF INDUCTOR
Frequency - Self Resonant 24MHz
Max DC Current 230mA
DC Resistance (DCR) 2.2Ohm Max
Test Frequency 2.5MHz
Inductance 22μH
Lead Diameter 0.635 mm
Lead Length 36.58mm
Current Rating 230mA
Number of Functions 1
Shielding Unshielded
Packing Method TR, 14 INCH
HTS Code 8504.50.80.00
Terminal Finish Tin/Lead (Sn63Pb37)
Type Molded
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code no
JESD-609 Code e0
Tolerance ±5%
Size / Dimension 0.187Diax0.437L 4.75mmx11.10mm
Series ER1840
Published 2012
Packaging Tape & Reel (TR)
Operating Temperature -55°C~105°C
Physical
Shape/Size Description TUBULAR PACKAGE
Material - Core Iron
Weight 949.99252mg
Terminal Shape WIRE
Package / Case Axial
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 15 Weeks
