ER1641-274KR
RoHS
/
Package Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description
Non-RoHS Compliant Molded Active WIRE Fixed Inductor -55C~105C 7MHz 5.8Ohm Max 270muH
PDF
/
Inventory: 6781
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Axial
Terminal Shape WIRE
Material - Core Ferrite
Shape/Size Description TUBULAR PACKAGE
Technical
Operating Temperature -55°C~105°C
Packaging Tape & Reel (TR)
Published 2012
Series ER1641
Size / Dimension 0.162Diax0.410L 4.11mmx10.41mm
Tolerance ±10%
JESD-609 Code e0
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 2
ECCN Code EAR99
Type Molded
Terminal Finish Tin/Lead (Sn63Pb37)
HTS Code 8504.50.80.00
Packing Method TR, 14 INCH
Shielding NO
Number of Functions 1
Current Rating 115mA
Lead Length 36.53mm
Inductance 270μH
Test Frequency 790kHz
DC Resistance (DCR) 5.8Ohm Max
Max DC Current 115mA
Frequency - Self Resonant 7MHz
Inductor Application RF INDUCTOR
Q @ Freq 55 @ 790kHz
Quality Factor-Min (at L-nom) 55
Q Factor 55
Dimensions
Diameter 4.11mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
