9250A-274-TR-RC
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description
9250A Axial 0.162Diax0.410L 4.11mmx10.41mm 270muH
PDF
/
Inventory: 7753
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mounting Type Through Hole
Package / Case Axial
Surface Mount NO
Terminal Shape WIRE
Material - Core Ferrite
Shape/Size Description TUBULAR PACKAGE
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Published 2009
Series 9250A
Size / Dimension 0.162Diax0.410L 4.11mmx10.41mm
Tolerance ±10%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Molded
Terminal Finish Matte Tin (Sn)
HTS Code 8504.50.80.00
Packing Method TR
Shielding YES
Number of Functions 1
Construction Cylindrical
Military Standard Not
Lead Length 25.4mm
Lead Diameter 635 μm
Inductance 270μH
Test Frequency 790kHz
DC Resistance (DCR) 5.8Ohm Max
Max DC Current 115mA
Frequency - Self Resonant 7MHz
Inductor Application RF INDUCTOR
Q @ Freq 55 @ 790kHz
Quality Factor-Min (at L-nom) 55
Current - Saturation 70mA
Q Factor 55
DC Current 115mA
Dimensions
Diameter 4.11mm
Compliance
RoHS Status ROHS3 Compliant
