5500R-103K
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR ROHS3Compliant Active WRAPAROUND fixed air core inductor -55C~130C 1kHz 16mOhm Max 10muH
PDF
/
Inventory: 3776
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape WRAPAROUND
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -55°C~130°C
Packaging Tape & Reel (TR)
Published 2011
Series 5500R
Size / Dimension 1.050Lx0.495W 26.67mmx12.57mm
Tolerance ±10%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
HTS Code 8504.50.80.00
Packing Method TR, Paper, 13 Inch
Shielding NO
Number of Functions 1
Depth 12.96mm
Construction Rectangular
Current Rating 7.88A
Inductance 10μH
Test Frequency 1kHz
DC Resistance (DCR) 16mOhm Max
Max DC Current 7.88A
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Inductor Type GENERAL PURPOSE INDUCTOR
Current - Saturation 5.71A
Dimensions
Height 13.21mm
Height Seated (Max) 0.520 13.21mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
