5022R-333H

API Delevan Inc.
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description 5022R Nonstandard 0.520Lx0.250W 13.21mmx6.35mm 33muH
PDF
/
Inventory: 7867
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Height Seated (Max) 0.230 5.84mm
Height 5.84mm

Technical

Case/Size Code 5024
Q Factor 65
Inductor Type GENERAL PURPOSE INDUCTOR
Quality Factor-Min (at L-nom) 65
Q @ Freq 65 @ 2.5MHz
Terminal Placement DUAL ENDED
Inductor Application RF INDUCTOR
Frequency - Self Resonant 19MHz
Max DC Current 337mA
DC Resistance (DCR) 3Ohm Max
Test Frequency 2.5MHz
Inductance 33μH
Current Rating 337mA
Construction Epoxy Molded
Depth 6.35mm
Number of Functions 1
Shielding NO
Packing Method TR, 13 Inch
HTS Code 8504.50.80.00
Terminal Finish Tin/Silver/Copper (Sn96.5Ag3.0Cu0.5)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e1
Tolerance ±3%
Size / Dimension 0.520Lx0.250W 13.21mmx6.35mm
Series 5022R
Published 2007
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C

Physical

Shape/Size Description RECTANGULAR PACKAGE
Material - Core Iron
Terminal Shape WRAPAROUND
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 45 Weeks
