ELT-5KT330LB
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
5KT Nonstandard 0.228Lx0.205W 5.80mmx5.20mm 33muH
PDF
/
Inventory: 4128
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 0.047 1.20mm
Height 1.1mm
Diameter 5mm
Technical
Special Feature DCR IS MEASURED AT 20% TOLERANCE
Case/Size Code 2623
Terminal Placement DUAL ENDED
Inductor Application DC-DC CONVERTER
Max DC Current 360mA
DC Resistance (DCR) 1.2Ohm
Test Frequency 100kHz
Inductance 33μH
Current Rating 360mA
Construction Chip
Depth 6mm
Number of Functions 1
Shielding NO
Packing Method TR
HTS Code 8504.50.80.00
Terminal Finish Tin/Copper (Sn/Cu)
Type Wirewound
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e2
Tolerance ±15%
Size / Dimension 0.228Lx0.205W 5.80mmx5.20mm
Series 5KT
Published 2008
Packaging Tape & Reel (TR)
Physical
Shape/Size Description RECTANGULAR PACKAGE
Terminal Shape FLAT
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
