4922R-33L

API Delevan Inc.
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description 4922R Nonstandard 0.505Lx0.240W 12.82mmx6.09mm 470muH
PDF
/
Buying Options
Total Price: USD $3.77
Unit Price: USD $3.7664
≥1 USD $3.7664
≥10 USD $3.15216
≥100 USD $2.877952
≥500 USD $2.466992
≥1000 USD $2.261336
≥3000 USD $2.192854
Inventory: 1147
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Width 6.096mm
Length 12.827mm
Height Seated (Max) 0.230 5.84mm
Height 5.84mm

Technical

Current - Saturation 350mA
Inductance Frequency - Test 1kHz
Max DC Current 350mA
DC Resistance (DCR) 3.25Ohm Max
Test Frequency 1kHz
Inductance 470μH
Current Rating 350mA
Depth 6.35mm
Shielding Unshielded
Current Rating (Amps) 350mA
Composition Wirewound
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Type Wirewound
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±15%
Size / Dimension 0.505Lx0.240W 12.82mmx6.09mm
Series 4922R
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C

Physical

Material - Core Ferrite
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 45 Weeks
