4922-221J

API Delevan Inc.
RoHS
/
Package 2-SMD
Category Inductors, Coils, Chokes / Fixed Inductors
Description Non-RoHS Compliant Wirewound Active WRAPAROUND fixed air core inductor -55C~125C 1kHz 8mOhm Max 220nH
PDF
/
Inventory: 5793
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Number of Functions 1
Depth 6.35mm
Construction Epoxy Molded
Current Rating 7A
Inductance 220nH
Test Frequency 1kHz
DC Resistance (DCR) 8mOhm Max
Max DC Current 7A
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Shielding NO
Packing Method TR
HTS Code 8504.50.80.00
Terminal Finish Tin/Lead (Sn63Pb37)
Type Wirewound
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e0
Tolerance ±5%
Size / Dimension 0.520Lx0.250W 13.21mmx6.35mm
Series 4922
Published 2012
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C

Dimensions

Height 5.84mm
Height Seated (Max) 0.230 5.84mm

Compliance

Radiation Hardening No
RoHS Status Non-RoHS Compliant

Physical

Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Number of Pins 2
Terminal Shape WRAPAROUND
Package / Case 2-SMD
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 45 Weeks
