4379-274KS
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR Non-RoHS Compliant Active Contains Lead fixed air core inductor -55C~125C 5.2MHz 8.1Ohm Max 270muH
PDF
/
Inventory: 3666
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 0.140 3.56mm
Height 3.56mm
Technical
Case/Size Code 1613
Q Factor 85
Inductor Type GENERAL PURPOSE INDUCTOR
Quality Factor-Min (at L-nom) 85
Q @ Freq 85 @ 790kHz
Terminal Placement DUAL ENDED
Inductor Application RF INDUCTOR
Frequency - Self Resonant 5.2MHz
Max DC Current 78mA
DC Resistance (DCR) 8.1Ohm Max
Test Frequency 790kHz
Inductance 270μH
Current Rating 78mA
Construction Rectangular
Depth 3.38mm
Number of Functions 1
Shielding YES
Packing Method TR, 13 Inch
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Part Status Active
Pbfree Code no
Tolerance ±10%
Size / Dimension 0.155Lx0.125W 3.93mmx3.17mm
Series 4379
Published 2002
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Terminal Shape WRAPAROUND
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 15 Weeks
