3483-270M
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
Non-RoHS Compliant Wirewound Obsolete Contains Lead Fixed Inductor -20C~80C 100kHz 240mOhm Max 27muH
PDF
/
Inventory: 7172
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape FLAT
Material - Core Ferrite
Shape/Size Description CYLINDRICAL PACKAGE
Technical
Operating Temperature -20°C~80°C
Packaging Tape & Reel (TR)
Published 2002
Series 3483
Size / Dimension 0.287Lx0.287W 7.30mmx7.30mm
Tolerance ±20%
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Wirewound
Terminal Finish Tin/Lead (Sn63Pb37)
HTS Code 8504.50.80.00
Packing Method TR
Shielding NO
Number of Functions 1
Depth 7.6mm
Current Rating 800mA
Inductance 27μH
Test Frequency 100kHz
DC Resistance (DCR) 240mOhm Max
Max DC Current 800mA
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Case/Size Code 3030
Dimensions
Height 3.3mm
Height Seated (Max) 0.138 3.50mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
