2512-332K

API Delevan Inc.
RoHS
/
Package 2-SMD, J-Lead
Category Inductors, Coils, Chokes / Fixed Inductors
Description GENERAL PURPOSE INDUCTOR Non-RoHS Compliant Active Contains Lead fixed air core inductor -55C~125C 7.9MHz 750mOhm Max 3.3muH
PDF
/
Inventory: 6526
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 2-SMD, J-Lead
Terminal Shape WRAPAROUND
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE

Technical

Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Published 2001
Series 2512
Size / Dimension 0.245Lx0.095W 6.22mmx2.41mm
Tolerance ±10%
JESD-609 Code e0
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn63Pb37)
HTS Code 8504.50.80.00
Packing Method TR, 13 Inch
Shielding NO
Number of Functions 1
Depth 2.67mm
Construction Rectangular
Current Rating 734mA
Inductance 3.3μH
Test Frequency 7.9MHz
DC Resistance (DCR) 750mOhm Max
Max DC Current 734mA
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Inductor Type GENERAL PURPOSE INDUCTOR
Current - Saturation 551mA
Case/Size Code 2611

Dimensions

Height 2.79mm
Height Seated (Max) 0.110 2.79mm

Compliance

Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
