2512-103K
RoHS
/
Package 2-SMD, J-Lead
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR Non-RoHS Compliant Active Contains Lead fixed air core inductor -55C~125C 7.9MHz 1.5Ohm Max 10muH
PDF
/
Inventory: 1135
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 2-SMD, J-Lead
Terminal Shape WRAPAROUND
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Published 2010
Series 2512
Size / Dimension 0.245Lx0.095W 6.22mmx2.41mm
Tolerance ±10%
JESD-609 Code e0
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn63Pb37)
HTS Code 8504.50.80.00
Packing Method TR, 13 Inch
Shielding NO
Number of Functions 1
Depth 2.67mm
Construction Rectangular
Current Rating 519mA
Inductance 10μH
Test Frequency 7.9MHz
DC Resistance (DCR) 1.5Ohm Max
Max DC Current 519mA
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Inductor Type GENERAL PURPOSE INDUCTOR
Current - Saturation 389mA
Case/Size Code 2611
Dimensions
Height 2.79mm
Height Seated (Max) 0.110 2.79mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
