2474R-17L
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description
2474R Axial 0.240Diax0.740L 6.10mmx18.80mm 22muH
PDF
/
Buying Options
Total Price: USD $4.85
Unit Price: USD $4.853588
≥1 USD $4.853588
≥10 USD $4.578859
≥100 USD $4.319672
≥500 USD $4.075163
≥1000 USD $3.844494
Inventory: 935
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter 6.1mm
Technical
Current - Saturation 1.4A
Inductor Application POWER INDUCTOR
Max DC Current 2.66A
DC Resistance (DCR) 50mOhm Max
Test Frequency 1kHz
Inductance 22μH
Lead Length 36.6mm
Current Rating 2.66A
Construction Tubular
Number of Functions 1
Shielding NO
Packing Method TR, 14 INCH
HTS Code 8504.50.80.00
Terminal Finish Tin/Copper (Sn99.3Cu0.7)
Type Molded
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e2
Tolerance ±15%
Size / Dimension 0.240Diax0.740L 6.10mmx18.80mm
Series 2474R
Published 2005
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Shape/Size Description TUBULAR PACKAGE
Material - Core Ferrite
Terminal Shape WIRE
Package / Case Axial
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 30 Weeks
