1944R-15G
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description
ROHS3Compliant Molded Active WIRE fixed air core inductor -55C~125C 160MHz 380mOhm Max 1.5muH
PDF
/
Inventory: 9243
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter 4.9mm
Technical
Special Feature Q MEASURED AT 15 MHZ
Q Factor 45
Quality Factor-Min (at L-nom) 45
Q @ Freq 45 @ 15MHz
Inductor Application RF INDUCTOR
Frequency - Self Resonant 160MHz
Max DC Current 850mA
DC Resistance (DCR) 380mOhm Max
Test Frequency 7.9MHz
Inductance 1.5μH
Lead Length 33.02mm
Current Rating 850mA
Number of Functions 1
Shielding NO
Packing Method TR
HTS Code 8504.50.80.00
Terminal Finish Tin/Copper (Sn99.3Cu0.7)
Type Molded
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
JESD-609 Code e2
Tolerance ±2%
Size / Dimension 0.193Diax0.447L 4.90mmx11.35mm
Series 1944R
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Shape/Size Description TUBULAR PACKAGE
Material - Core Phenolic
Terminal Shape WIRE
Package / Case Axial
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 15 Weeks
