1840-05F
RoHS
/
Package Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description
Non-RoHS Compliant Molded Active Axial fixed air core inductor -55C~125C 300MHz 80mOhm Max 390nH
PDF
/
Inventory: 6049
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Length 11.0998mm
Diameter 4.75mm
Technical
Q Factor 55
Inductance Frequency - Test 25MHz
Lead/Base Style Axial
Q @ Freq 55 @ 25MHz
Frequency - Self Resonant 300MHz
Max DC Current 1.86A
DC Resistance (DCR) 80mOhm Max
Test Frequency 25MHz
Inductance 390nH
Current Rating 1.86A
Shielding Unshielded
Current Rating (Amps) 1.86A
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Type Molded
Termination Axial
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Tolerance ±1%
Size / Dimension 0.187Diax0.437L 4.75mmx11.10mm
Series 1840
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Material - Core Phenolic
Package / Case Axial
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 15 Weeks
