1641R-472K
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description
1641R Axial 0.162Diax0.410L 4.11mmx10.41mm 4.7muH
PDF
/
Buying Options
Total Price: USD $5.15
Unit Price: USD $5.1534
≥1 USD $5.1534
≥10 USD $4.861693
≥100 USD $4.586509
≥500 USD $4.326902
≥1000 USD $4.081981
Inventory: 1394
Minimum: 1
-
+
Technical Details
Physical
Mount PCB, Through Hole
Mounting Type Through Hole
Package / Case Axial
Terminal Shape WIRE
Weight 1g
Material - Core Iron
Shape/Size Description TUBULAR PACKAGE
Technical
Operating Temperature -55°C~105°C
Packaging Bulk
Published 2005
Series 1641R
Size / Dimension 0.162Diax0.410L 4.11mmx10.41mm
Tolerance ±10%
JESD-609 Code e3
Pbfree Code yes
Part Status Last Time Buy
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 2
ECCN Code EAR99
Type Molded
Terminal Finish Tin (Sn)
HTS Code 8504.50.80.00
Packing Method TR, 14 INCH
Shielding YES
Number of Functions 1
Construction Tubular
Current Rating 390mA
Reference Standard MS75088
Lead Length 36.6mm
Inductance 4.7μH
Test Frequency 7.9MHz
DC Resistance (DCR) 550mOhm Max
Max DC Current 390mA
Frequency - Self Resonant 70MHz
Inductor Application RF INDUCTOR
Q @ Freq 44 @ 7.9MHz
Quality Factor-Min (at L-nom) 44
Q Factor 44
Dimensions
Diameter 254μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
