1641-823H
RoHS
/
Package Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description
1641 Axial 0.162Diax0.410L 4.11mmx10.41mm 82muH
PDF
/
Inventory: 9305
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Diameter 4.11mm
Technical
Q Factor 50
Current - Saturation 140mA
Quality Factor-Min (at L-nom) 50
Q @ Freq 50 @ 2.5MHz
Inductor Application RF INDUCTOR
Frequency - Self Resonant 10.5MHz
Max DC Current 186mA
DC Resistance (DCR) 2.44Ohm Max
Test Frequency 2.5MHz
Inductance 82μH
Lead Length 36.58mm
Current Rating 186mA
Number of Functions 1
Shielding YES
Packing Method TR
Terminal Finish Tin/Lead (Sn63Pb37)
Type Molded
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Last Time Buy
Pbfree Code no
JESD-609 Code e0
Tolerance ±3%
Size / Dimension 0.162Diax0.410L 4.11mmx10.41mm
Series 1641
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature -55°C~105°C
Physical
Shape/Size Description TUBULAR PACKAGE
Material - Core Ferrite
Terminal Shape WIRE
Package / Case Axial
Mounting Type Through Hole
Mount Through Hole
