160-564JS
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
Fixed Inductors 560uH 5% 81ohm Chip SMT Inductor
PDF
/
Inventory: 4226
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 0.080 2.03mm
Height 2.03mm
Technical
Case/Size Code 1613
Q Factor 28
Inductor Type GENERAL PURPOSE INDUCTOR
Quality Factor-Min (at L-nom) 28
Q @ Freq 28 @ 790kHz
Terminal Placement DUAL ENDED
Inductor Application RF INDUCTOR
Frequency - Self Resonant 2.8MHz
Max DC Current 40mA
DC Resistance (DCR) 81Ohm Max
Test Frequency 790kHz
Inductance 560μH
Current Rating 40mA
Construction Chip
Depth 3.18mm
Number of Functions 1
Shielding NO
HTS Code 8504.50.80.00
Terminal Finish Tin/Lead (Sn63Pb37)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Part Status Active
Pbfree Code no
JESD-609 Code e0
Tolerance ±5%
Size / Dimension 0.150Lx0.120W 3.81mmx3.05mm
Series 160
Published 2002
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Terminal Shape WRAPAROUND
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 15 Weeks
